7. MENU
7.5. MENU TREE
FIRST LEVEL SECOND LEVEL THIRD LEVEL SYSTEM
UNIT IN A
SYSTEM
ALARMS
SYSTEM X
UNIT1 X
UNIT2 X
UNIT3 X
UNIT X
MODULE 1 X
MODULE 2 X
MODULE 3 X
MODULE 4 X
MODULE 5 X
MODULE 6 X
MODULE 7
X
MODULE 8
X
BYPASS
X
STATUS
SYSTEM X
UNIT1 X
UNIT2 X
UNIT3 X
UNIT X
MODULE 1 X
MODULE 2 X
MODULE 3 X
MODULE 4 X
MODULE 5 X
MODULE 6 X
MODULE 7 X
MODULE 8 X
BYPASS X
MEASUREMENTS
OUTPUT MEASURES X X
BATTERIES MEASURES X X
INPUT MEASURES X X
BYPASS X X
SUBUNIT MEASURES X
CONTROLS
ALARMS RESET Alarms Reset X X
UPS PROCEDURES Automatic Start Procedure X
Automatic Stop Procedure X
On Mainten. Bypass Procedure X
ECO MODE Activate Eco Mode X
Return to Normal Mode X
BATTERY TEST Battery Test X
(1)
X
(2)
LED BAR TEST Led Bar Test X X
