socomec MODULYS GP User Manual

27
ENGLISHENGLISH
MODULYS GP Green Power 2.0 range from 400 to 600 kVA - Ref.: IOMMODGPXX07-EN 00
5-1
MODULYS GP 400 kVA
5-2
MODULYS GP 600 kVA
5. CONNECTIONS
NOTE!
Before carrying out any operations on the unit read the Safety standards chapter carefully.
DANGER! RISK OF ELECTRIC SHOCK!
Check the presence of voltage before operating.
DANGER! RISK OF ELECTRIC SHOCK!
Battery power terminals can be supplied by:
- external battery cabinet;
- UPS power modules.
Before working on this circuit ensure that:
- all the external battery cabinet switches are in OFF position;
- all UPS power modules are disconnected;
POSITION
B
POSITION
A
COUPLING
CABINET
POSITION
C
COUPLING
CABINET
POSITION
B
POSITION
A

socomec MODULYS GP Specifications

General

Topology	Double Conversion Online
Frequency	50/60 Hz
Efficiency	Up to 96%
Modular	Yes
Input Voltage	400 V
Output Voltage	400 V
Battery Type	VRLA
Communication Ports	RS232, USB, SNMP
Operating Temperature	0 to +40 °C
Humidity	Up to 95 % non-condensing
