socomec MODULYS GP User Manual

37
MODULYS GP Green Power 2.0 range from 400 to 600 kVA - Ref.: IOMMODGPXX07-EN 00
ENGLISH
Block reference
Reference
terminal
Input/Output Detail reference terminal Screw to install
Recommended
tightening torque [Nm]
X100
INPUT MAINS
N M12 40 - 45
L1 M12 40 - 45
L2 M12 40 - 45
L3 M12 40 - 45
INPUT MAINS UNIT 1-2-3
N M12 40 - 45
L1 M12 40 - 45
L2 M12 40 - 45
L3 M12 40 - 45
X80 AUXILIARY MAINS
N M12 40 - 45
L1 M12 40 - 45
L2 M12 40 - 45
L3 M12 40 - 45
X61
X62
X63
AUXILIARY MAINS UNIT 1-2-3
L1 M10 20 - 26
L2 M10 20 - 26
L3 M10 20 - 26
X70 OUTPUT UNIT 1-2-3
N M10 20 - 26
L1 M10 20 - 26
L2 M10 20 - 26
L3 M10 20 - 26
X90 OUTPUT TO LOAD
N M12 40 - 45
L1 M12 40 - 45
L2 M12 40 - 45
L3 M12 40 - 45
X200 BATTERY
+ M10 20 - 26
- M10 20 - 26
N M10 20 - 26
5. CONNECTIONS
