socomec MODULYS GP User Manual

62
MODULYS GP Green Power 2.0 range from 400 to 600 kVA - Ref.: IOMMODGPXX07-EN 00
10-2
9. STANDARD FEATURES AND OPTIONS
TOP AIR EXHAUST
NET VISION CARD
NET VISION is a communication and management interface designed for business networks. The UPS behaves exactly like a
networked peripheral, it can be managed remotely, and allows the shutdown of network workstations.
NET VISION allows a direct interface between the UPS and LAN network avoiding dependence on the server and support SMTP,
SNMP, DMCP and many other protocols. it interacts via the web browser.
MODBUS RTU / MODBUS TCP
With the RTU/TCP card fitted in the options slot, the UPS can be monitored from remote stations using the appropriate protocol (RTU/TCP).
ENVIRONMENTAL confi guration
XJ2: ON - XJ3: ON
IN/OUT Description Filter (s) Status
IN1 UPS Power O 1 NO
IN2 Programmable Alarm 10 NC
IN3 Battery Temperature Alarm 10 NC
OUT1 General Alarm 10 NO/NC
OUT2 Battery Temperature Alarm 10 NO
OUT3 Overload or Redundancy lost 10 NO
OUT4 Programmable Alarm 10 NO
SAFETY confi guration
XJ2: OFF - XJ3: ON
IN/OUT Description Filter (s) Status
IN1 UPS Power O 1 NO
IN2 Insulation Fault 1 NC
IN3 Charger Disable/Enable 10 NC
OUT1 General Alarm 10 NO/NC
OUT2 UPS Power O activated 1 NO
OUT3
Battery Low / Imminent UPS stop alarm 10 NO
OUT4 Insulation Fault 1 NO
(1). The ADC card has the possibility of connecting an external NTC sensor, to measure the external battery cabinet temperature.

socomec MODULYS GP Specifications

General

Topology	Double Conversion Online
Frequency	50/60 Hz
Efficiency	Up to 96%
Modular	Yes
Input Voltage	400 V
Output Voltage	400 V
Battery Type	VRLA
Communication Ports	RS232, USB, SNMP
Operating Temperature	0 to +40 °C
Humidity	Up to 95 % non-condensing
