HYD 5/6/8/10/15/20KTL-3PH USER MANUAL
116
Model
HYD
5KTL-3PH
HYD
6KTL-3PH
HYD
8KTL-3PH
HYD
10KTL-3PH
HYD
10KTL-3PH-A
HYD
15KTL-3PH
HYD
20KTL-3PH
Rated Output Current
7.6/7.2/6.9A
9.1/8.7/8.3A
12.1/11.6/11.1A
15.2/14.5/13.9A
15.2/14.5/13.9A
22.7/21.7/20.8A
30.3/29.0/27.8A
Rated Output Voltage
3N~+PE, 380/400/415 Va.c.
Rated Output Frequency
50/60Hz
Rated Apparent Power
5 kVA
6 kVA
8 kVA
10 kVA
10 kVA
15 kVA
20 kVA
Max. Apparent Power
5.5 kVA
6.6 kVA
8.8 kVA
11 kVA
11 kVA
16.5 kVA
22 kVA
Peak Output Apparent
Power
7500VA,
60s
9000VA,
60s
12000VA,
60s
15000VA,
60s
15000VA,
60s
22500VA,
60s
26000VA,
60s
Max. Output Current
8.3/8.0/7.6A
10.0/9.6/9.2A
13.3/12.8/12.2A
16.7/15.9/15.3A
15.2/14.5/13.9A
25.0/23.9/22.9A
33.3/31.9/30.6A
THDv(@ linear load)
<3%
Switching Time
10ms default
Efficiency
Max. MPPT Efficiency
99.9%
Max. Efficiency
98.0%
98.0%
98.0%
98.2%
98.2%
98.2%
98.2%
European Efficiency
97.5%
97.5%
97.5%
97.7%
97.7%
97.7%
97.7%
Max. Efficiency of
Charging/Discharging [4]
97.6%
97.6%
97.6%
97.8%
97.8%
97.8%
97.8%
Protection
DC Switch
Yes
PV Reverse Connection
Protection
Yes
Battery Reverse Connection
Protection
Yes
Output Short Circuit
Protection
Yes
Output Overcurrent
Protection
Yes
Output Overvoltage
Protection
Yes
Insulation Impedance
Detection
Yes
Residual Current Detection
Yes
Anti-island Protection
Yes
Surge Protection
PV:Type
Ⅱ
，
AC:Type
Ⅱ
General Parameters
Operating Temperature
Range
-30
℃
to 60
℃
(derating above +45
℃
）
Relative Humidity Range
5%-95%
Max. Operating Altitude
4000m (derating above 2000 m)
Standby Self-consumption
[5]
<25W
Inverter Topology
Non-Isolation
Installation Method
Wall Mounted
IP Rating
IP65
Dimensions (W*H*D)
587*515*261 mm
Cooling Mode
Natural
Forced airflow
Weight
33 kg
33 kg
33 kg
37kg
37kg
37kg
37kg
