Sojet V1H - Logo Object Creation; Logo Import and Editing; Logo Specification Settings; Logo Positioning

24
 Select the image from the list.
 Set the name of the local image source: Maximum 30 characters, Chinese or English characters,
numbers, symbols, name cannot be blank or overlapped.
 At last, click 【Return】to save.
Add Local Image in New Logo Object
 【New】>【New Object】>【Logo】
 Click , select the logo type, types including Local image or Base image.
 Click 【Local Image】, the images in the selected type will be displayed in the list.
 Select the image from the list and set the name of the local image source, click 【Return】to save.
 Select a source in the image source list, click to edit.
 Click to set the logo’s specifications.
Width ratio: range from 10-300, the width of the picture will be adjusted automatically.
Height ratio: range from 10-300, the height of the picture will be adjusted automatically.
Lock Percentage: After selected, the height and width of the picture will be adjusted with the same proportion.
 Click , user can do the position setting on X/Y axis.
X axis: Range -10-3000mm, adjust by
Y axis: Range depends on the canvas size, also can be adjusted by .
 Click to rotate the image.
Rotate: rotation angel from 0-359, user may click to adjust as well.
Mirror: three options: none, Horizontal, Vertical.
Gradation: Printing darkness can be set within 10-100%.
 Click to name the logo: Maximum 30 characters, Chinese or English characters, numbers,
symbols, name cannot be blank or overlapped.
 Click to save and return to upper menu.
Save Message
Please refer to Save Message
