【Adaptive screen】: Display canvas size in 1:1 ratio.
 Click 【Tools】again, the toolbar will be hided.
 Click every time, the preview interface will add one line canvas, multi-line data can be built to
maximum 16 lines.
 Click every time, the preview interface will reduce one line canvas.
4.2.4 New Message
【Message】>【New】>【New object】
 Select object enter to the setting interface (text, counter, date time, shift, scan, barcode, local picture)
 After setting parameters, click 【return】to save the object
 Selected object in the object list , click 【Edit object】to modified object ,click to save.
 Click again to save message and return to the message management interface.
4.2.4.1 Text object
【Message】>【New】>【New object】>【Text】
 【Input】: Default text content : EXAMPLE TEXT, can enter Chinese, English, numbers, symbols,
other language, 100 characters.
【Character】:
Font: Select the font.
Size: Set the font size.
Font effect: Bold, Italic, Add under horizontal line, Add font with horizontal
line
Cut Edge: Set whether the objet with white lace.
 【Location】
X axis coordinates: Input range -10-3000mm, you can click buttons to adjust slightly.
Y axis coordinates: Input range according to canvas amount limited, also can click buttons to
adjust slightly.
Width: You can enter 10% to 300%, the greater value, the larger width font.
Height: You can enter 10% to 300%, the greater value, the higher font.
