Sojet V1H - Barcode Shortcuts; Barcode Type and Genre Selection; Barcode Configuration Settings; Barcode Object Positioning and Naming

27
 【Shortcut】: Can add Text/Counter/Shift/Data Time/Dynamic Text/ Database Text/Device
Info/line break into barcode object. (Tip: Add scan source and scan the illegal value, the scan source will
change to 00000 in the bar code)
Note: Refer to above create text object about add “source”.
 Click 【type】to select the required barcode type.
 Click【Genre】, user can select 1Dbarcode, 2D barcode.
 User will see the barcode types required.
 Barcode Settings
Note: 1D and 2D barcodes have different settings, user need to select barcode genre firstly.
Barcode type
Settings
1D Barcode
Width: Totally 1-16 levels to choose from.
Height: Within the canvas size,1-12.7mm
Font: Select barcode text font
Font Size: Select barcode text font size.
Text Display: User can switch from on or off.
Cut Edge: Select barcode whether with white lace
Blank Level: 0-4 grades to switch.
2D Barcode
Width: Totally 1-16 levels to choose from.
Error Correction Level: QR code, 1-4 grades;
PDF417, 1-7 grades.
Blank Level: 0-4 grades to switch.
Size: QR, DATAMATRIX bar code size
specifications.
 Location, Rotation, Name please refer to Create Text Object
Save Message
Please refer to Save Message
