Sojet V1H - Barcode Type Selection; Barcode Specification Settings; Barcode Object Positioning and Naming

43
【Type】:
Genre: Select 1Dbarcode, 2D barcode.
Type: Select barcode type.
【Specification】: Note: 1D and 2D barcodes have different settings, user need to select barcode
genre firstly.
Barcode type
Settings
1D Barcode
Width: Totally 1-16 levels to choose from.
Height: Within the canvas size,1-12.7mm
Font: Select barcode text font
Font Size: Select barcode text font size.
Text Display: User can switch from on or off.
Cut Edge: Select barcode whether with white lace
Blank Level: 0-4 grades to switch.
2D Barcode
Width: Totally 1-16 levels to choose from.
Error Correction Level: QR code, 1-4 grades;
PDF417, 1-7 grades.
Blank Level: 0-4 grades to switch.
Size: QR/DATAMATRIX bar code size
specifications.
 【Location】
X axis coordinates: Input range -10-3000mm, you can click buttons to adjust slightly.
Y axis coordinates: Input range according to canvas amount limited, also can click buttons to
adjust slightly.
Width: You can enter 10% to 300%, the greater value, the larger width font.
Height: You can enter 10% to 300%, the greater value, the higher font.
Lock scale: The proportion of barcode height and width. After select this function, when modify the font width or
height, the font will be proportionally adjusted. Tips: If the data location beyond the canvas, it will turn yellow,
after saving only the content within the canvas can be printed.
