5. Proceed as follows:
Parameter Input
PIN (2x) PIN of the SIM card according to card contract
APN APN of the network operator
PPP Username GPRS user name of the network operator
PPP Password (2x) GPRS password of the network operator
The other elds must not be changed.
6. Click on “Save” (do not click on the Restart button).
7. Switch MaxWeb xp off (see Section 6.1).
Installing the SIM card
8. Fully disconnect the MaxWeb xp from the power supply by pulling the plug-in mains
unit from the socket.
9. Release the four screws under the edge of the cover and lift it off.
