SolaX Power X1-EVC Series User Manual

32
Installation and Wiring
• Communication with Network
Network connection is optional for areas where remote WiFi connection is not
available or has a weak signal. Users can choose to finish the network connection
as needed.
Connect the commmunication cable for network to the Network port on the
base plate of communication board.
Figure 6-30 Connect the communication cable to Network port
WARNING!
• The Ethernet cable used to connect the EV-Charger for communication must be
protected from lightning strikes.
