55
Operation Method
The user can set the charging current level for Eco mode on the setting page of the App
following the path: Charger setting > Work mode setting > Eco.
Cancel OK
Green Eco3A 6A
6A 10A
16A
20A
Figure 9-12 Charging current level for Eco mode
NOTICE!
When the EV-Charger is charging in Green or Eco mode:
• The charging electric vehicle must comply with the IEC61851 standard, otherwise the
EV-Charger won't work.
• If there is a zero injection requirement for the system, the EV-Charger must
communicate with the inverter in order to charge normally.
Fast mode
In Fast mode, the EV-Charger will charge the EV at the fastest rate regardless of whether
the power generated by PV is sufficient and import grid electricity if the power generated
by PV is insufficient.
Charging Power
Fast mode
Max. Power
Energy from grid
Time
Energy from PV
Figure 9-13 Fast mode
