100 • Technical Specifications
PARAMETERS)
Heat Sink Over
Temperature:
Trips when heat-sink temperature rises above 85°C
External Fault: Trips when an external contact closes for 2 sec.
Motor Insulation
(optional):
Alarm and trip level setting 0.2 – 5MΩ, trips and alarms when insulation
decreases below levels set
Motor Thermistor
(optional):
Trip level setting 1-10KΩ, trips when resistance decreases below the level set
Note:
(1) Refer to section 6.5.5 page 58 for expanded setting
Control:
Displays: LCD in 4 – Field selectable languages and 8 LEDs
Keypad: 6 keys for easy setting
Aux Contact –
Immediate:
1 C/O, 8A, 250VAC, 2000VA
Aux Contact – End Of
Acceleration:
1 C/O, 8A, 250VAC, 2000VA
Fault Contact: 1 C/O, 8A, 250VAC, 2000VA
Insulation Alarm Contact
(optional):
1 C/O, 8A, 250VAC, 2000VA
Communication
(optional):
RS 485 with Modbus protocol for full control and supervision
Communication
(optional):
Profibus DPV1 for full control and supervision
Temperatures Operating: -10° to 50°C
Storage: -20° to 70°C
Standards:
Dielectric Test: 2500VAC
Degree of Protection: IP 20 for frame size A; IP 00 for frame sizes B, C, D, E, F, G
Pollution Degree: 3
EMC Emissions: EN 55011 CISPR 11 Class A
Immunity: EN 55082-2 ESD 8KV air, IEC 801-2;
Electric RF field 10 V/m, 20-1000Mhz, IEC 801-3
Fast transients 2KV, IEC 801-4
Safety: EN 600947-1 Related to safety requirements.
UL508C
Normal Service Conditions:
Altitude: Up to 1000m. For equipment to be used at higher altitudes consult the factory.
Humidity: 95% at 50°C or 98% at 45˚C
Fan and RVS-DN Consumption Ratings:
Size A (8-31A): No fan Total RVS-DN Consumption: 150VA
Size A (44-72A): Fan 35 VA Total RVS-DN Consumption 185VA
Size B: Fan 60 VA Total RVS-DN Consumption 210VA
Size C: Fans 105 VA (35VA x 3) Total RVS-DN Consumption 255VA
Size D, E, F, G Fans 150 VA (50VA x 3) Total RVS-DN Consumption 300VA
