Solcon RVS-DN 8 User Manual

98 • Trouble Shooting
_____________________________________________________________________________________________
23
9.1
Warranty Claim and Fault Inquiry
Representative Name: Country: Fax Number:
Model Number And Built
Options:
Example: 390 – 400 – 230 – 230 – 3 + 4 + 9 + B – S
RVS-DN _ _ _ _ - _ _ _ - _ _ _ - _ _ _ - _ + _ + _ + _ - _
Serial Number:
Purchasing Date:
Sale / Installation Date:
Failure Date:
Program Version:
STRT.DN- _ _ _ _ _ _
Press MODE + ∇, press SELECT twice, the LCD displays the program
version (e.g. STRT.DN-011197)
Connection Diagram & Supply Network Type. Circle the correct main supply and add or erase parts in the
drawing:
Star, Delta, with/without neutral or ground
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
N
L1 L2 L3
Start Stop
Line
Contactor
M
UVW
L1 b L2 b L3 b
Bypass
Contactor
22
23
24
25
26
27
28
29
Insulation
Alarm
Run Fault E.O.A
Application Description:
Details of Fault / Fault Message:
Define time of fault occurrence: (during start, after start, during soft stop,
end of soft stop, when closing B.P. contactor, when performing…)
Statistical Information RVS-DN Operative Information
Last Start Period: RVS-DN FLC:
Last Start Max. I Motor FLC:
Total Run Time: Initial Voltage:
Total Number Of Starts: Acceleration Time:
Last Trip: Current Limit:
Trip Current:
Total Number Of Trips:
Trip History :
