Solcon RVS-DN 8 User Manual

79 • Control Keypad
________________________________________________________________________________________________
7.7.5 Dual Adjustment Parameters – Page 4
DUAL A
DJUSTMENT
PARAMETERS
Displays in MAXIMIZED MODE only
(refer to section
6.5.1 page 56 for changing mode)
Display and Default
Values
Range Description Remarks
When D.ADJ: GENERATOR PARAMETERS is required, do the following:
• Program PROG. INPUT #8 to DUAL ADJUSTMENT (default setting). Refer to section
7.7.8 on page 83.
• Set dip switch #3 to on (refer to section
6.5.3 on page 57).
• Connect control inputs voltage to input terminal 8.
The following display appears:
D. ADJ: GENERATOR
PARAMETERS
DA: INIT. VOLT.
30%
DA: INIT. CURRENT
100%
10-50%
After reaching 50% the
display changes to:
DA: INITIAL CURRENT
100-400%.
Note:
The range of the DA:
INITIAL VOLTAGE can be
extended to
10-80% by using the
EXPANDED SETTING as
described in section
6.5.5
page 58.
Sets motor’s INITIAL
STARTING VOLTA
GE
in DA mode.
(Motor’s
torque
is directly
proportional to the
square of the voltage)
Refer to section
7.7.3 on
page 72 parameter:
INITIAL VOLTAGE
DA: CUR. LIMIT
400% OF FLA
100-400%.
Note:
The range of the DA:
CURRENT LIMIT can be
extended to
100-500% by using the
EXPANDED SETTING as
described in section
6.5.5
page 58.
Sets motor’s highest
current during starting
in DA mode.
Refer to section
7.7.3 on
page 72 parameter:
CUR
RENT LIMIT.
DA: ACC. TIME
10 SEC.
1-30sec.
Note:
The range of the DA: ACC.
TIME can be extended to
1-90 sec. by using the
EXPANDED SETTING as
described in section
6.5.5
page 58.
Sets ACCE
LERATION
TIME of the motor in
DA mode.
Refer to section
7.7.3 on
page 72 parameter: ACC.
TIME.
DA: DEC. TIME
10 SEC.
1–30sec.
Note:
The range of the DA: DEC.
TIME can be extended to
1-90 sec. by using the
EXPANDED SETTING as
described in section
6.5.5
page 58.
Sets DECE
LERATION
TIME of the motor in
DA mode.
Refer to section
7.7.4 on
page 77 parameter: DEC.
TIME.
DA: MOTOR FLA
31 AMP.
50-100% of STARTER FLC Sets motor’s FLA (Full
load Ampere) in DA
mode.
Refer to section
7.7.2 on
page 67 parameter:
MOT
OR FLA.
STORE ENABLE
D. ADJ. PARAMETERS
Same as STORE
ENABLE
MAIN PARAMETERS on
page 71.
