Solcon RVS-DN 8 User Manual

71 • Control Keypad
________________________________________________________________________________________________
MAIN PARAMETERS
- **** -
Displays in MINIMIZED MODE and MAXIMIZED MODE
Display and Default
Values
Range Description Remarks
STORE ENABLE
MAIN PARAMETERS
Storing
modified
parameters
To store selected parameters scroll through all
parameters until you reach STORE ENABLE
MAIN PARAMETERS, then press the Store key.
After you store a parameter successfully the
DATA SAVED OK message will display.
If RVS-DN fails to store the parameter the LCD
Will display the STORAGE ERROR message
(refer to section
9 on page 95 for more details).
Note
:
Pressing the Store key when the STORE
ENABLE XXXXX PARAMETERS message does
not appear on the display has no effect.
7.7.2.1 Overload Calculation
Note:
In the overload procedure measurement of the current is limited to 5 x motor FLA to prevent saturation from
affecting the calculation. Therefore the trip time at 5 x motor FLA will be identical to the trip time at 8 x motor
FLA.
The approximate trip time is calculated as follows:
where:
OLT represents OverLoad Trip setting – (default = 115%).
OLD represents OverLoad Trip Delay – trip delay at 5 x Motor FLA, (default = 4 sec).
Example 1: Motor FLA = 80A, actual current = 120A.
I
%
= 120 x 100 / 80 = 150%
If settings are as in the default then:
Example 2: The same motor and setting, but the current is 400A.
I
%
= 400 x 100 / 80 = 500%
If settings are as in the default then
Example 3: Motor FLA = 80A, actual current = 200A, Overload Delay (OLD) = 10
I
%
= 200 x 100 / 80 = 250%
[seconds]
6
OLD
OLTI
000,375,1
Time Trip O/L
2
2
%
×
−
=
FLAmotor
100
Current Actual I
%
×=
sec. 99
6
4
151501
000,375,1
Time Trip O/L
22
=×
−
=
sec. 4
6
4
151500
000,375,1
Time Trip O/L
22
=×
−
=
sec. 47
6
10
151250
000,375,1
Time Trip O/L
22
=×
−
=
