Total heat dissipation [Watt] – The total heat dissipation of the starter and other control devices
in the enclosure. If starter is frequently started, average power should be used.
6.3.2 Additional Ventilation
Use the following arrangement for forced ventilation of the RVS-DX’s enclosure:
6.3.3 UL, cUL Installation Instructions
Input power and output motor field wiring shall be copper conductors, rated 75ºC.
Use UL listed closed-loop connectors sized for the selected wire gauge.
Install connectors using the correct crimp tool recommended by the connector
manufacturer. Applies only to units bus bars.
Table showing corresponding wire size, terminal screw and closed-loop connector size.
Torque ratings for attachment of connector to bus bar (refer to table below).
Branch circuit protection, shall be provided per the NEC.
For units with UL cUL approval, refer to section Error! Reference source not found. on
page Error! Bookmark not defined..
