Solcon RVS-DX Series User Manual

42 • Control Keypad
________________________________________________________________________________________
7.6.9 135BI/O Programming Parameters – page 7
I/O PROGRAMMING
PARAMETERS
Displays in MAXIMIZED MODE only
(refer to section 7.6.3 on page 27 for changing mode)
Display and default
values
Range
Description
Remarks
PROG. INPUT C1
REMOTE RESET
START/STOP;
REMOTE RESET;
EXTERNAL FAULT;
SLOW SPD/REVERSE;
GEN. START/STOP;
DUAL ADJUSTMENT;
Sets
TERMINAL
C1 function
Refer to section 7.6.9.1 on page
43.
FAULT RELAY TYPE
FAULT
FAULT,
FAULT – FAIL SAFE
Sets FAULT
RELAY mode
of operation.
When configured to FAULT the
internal relay is energized upon
fault.
When configured to FAULT-FAIL
SAFE the relay is de-energized
upon fault. In this mode, while
normal operation, the fault relay is
energized.
Relay will also de-energize upon
control power outage.
PROG. AUX. RELAY
IMMEDIATE
IMMEDIATE/
END OF ACCEL.
Sets starter’s
AUX. RELAY
mode of
operation.
When configured to IMMEDIATE
– the AUX. RELAY closes its
contact at start signal (after
programmed “on delay” time has
elapsed) and open its contact at
the end of deceleration time (if
any) (after programmed “off delay”
time has elapsed).
When configured to END OF
ACCEL. -the AUX. RELAY closes
its contact at end of soft start
(after programmed “on delay” time
has elapsed) and open its contact
at the beginning of soft stop (if
any) (after programmed “off delay”
time has elapsed).
RELAY ON DELAY
0 SEC.
0–60sec.
Sets starter’s
AUX. RELAY
on delay
time.
RELAY OFF DELAY
0 SEC.
0–60sec.
Sets starter’s
AUX. RELAY
off delay time
AN. OUT PARAMETER
I, 0...200% OF FLA
I, 0...200% OF FLA
P, 0...200% OF Pn
POWER FACTOR
Sets
ANALOG
OUTPUT
mode of
operation.
Available only when analog card
is installed.
When analog card is installed, full
scale of the readings (20mA or
10V as per dip-switches settings)
are related to 200%FLA. (2x rated
motor current) or 200% of rated
power or POWER FACTOR.
Note:
POWER FACTOR & POWER
measurement only available in
RVS-DX58A and up.
STORE ENABLE
I/O PROG. PARAM.
Same as STORE ENABLE MAIN
PARAMETERS on page 29.
