59 • TECHNICAL SPECIFICATIONS:
___________________________________________________________________________________________
10. TECHNICAL SPECIFICATIONS:
Supply Voltage Line to Line 230-600V (to be specified) + 10%-15% for all models
Line to Line 690V (to be specified) + 10%-15% for RVS-DX 390A and up
Frequency 45 – 65 Hz (Fixed or variable frequency source)
Control Supply 115V or 230V (to be specified) +10% - 15%
Load Three phases, three wires, squirrel cage induction motor.
Start-Stop Parameters:
Starter FLC Starter’s Full Load Current, according to Selector Guide
Motor FLA Motor Full Load Ampere 50-100% of Starter FLC (Full Load Current).
Pump and Torque Control Curves Field selectable curves preventing Over-pressure during start and Water
Hammer during stop.
Pulse Start Duration A pulse of 80% Un, adjustable range 0.1-1 Sec, for starting high friction loads.
Initial Voltage, 5-80% Un
Initial Current 100-400% of Motor FLA
Current Limit 100-500% of Motor FLA
Acceleration Time 1-90 Sec
Deceleration Time 1-90 Sec
Motor Protection:
Too Many Starts Maximum number of starts, range: Off or 1-10, during a time period 1-60 min.
Starts inhibit Period of 1-60 min, during which starting is prevented, after Too Many Start
fault.
Long Start Time (Stall protection) Maximum allowable starting time 1-30 sec. (1-250sec. in WIDER SETTINGS)
Over Current (Shear-pin) Two operation functions: during starting trips the starter at 850% and during
running at 100-850% In, both within 1 Cycle (after internal delay).
Electronic Overload (I
2
t) Adjustable IEC and MEMA curves.
Under Current Trips when current drops below 20-90% In, time delay 1-40 sec.
Under Voltage* Trips when main voltage drops below 50-90%, time delay 1-10 Sec
Over Voltage Trips when main voltage increase above 110-125%, time delay 1-10 sec.
Phase Loss, Under/Over Frequency* Trips when one or two phases are missing and frequency is 45Hz. or 65Hz.
Phase Sequence Trips when phase sequence is wrong
Shorted SCR or Wrong connection Prevents starting, trips if motor is not connected / incorrectly connected to the
starter, or in case one or more SCRs have been shorted
Heat Sink Over temp Trips when heat-sink temperature rises above 85˚C.
External fault Trips when an External Contact closes for 2 sec.
* With optional Auto Reset.
Control:
Displays LCD in 4 – Field selectable languages and 4 LEDs.
Keypad 6 keys for easy setting
Fault Contact 2 Contacts, 8A, 250VAC, 2000VA
Aux. Contact – Imm. or End Of Acc. 2 Contacts, 8A, 250VAC, 2000VA
Temperatures: Operating -10˚ to 40˚C
Storage -20˚ to 70˚C
Standards:
Dielectric Test 2500VAC
Degree of Protection IP 20 for frame size D1, IP 00 for frame sizes D2-D5
EMC Emissions EN 55011 CISPR 11 Class A
Immunity EN 55082-2 ESD 8KV air, IEC 801-2
Electric RF field 10 V/m, 20-1000MHz, IEC 801-3
Fast transients 2KV, IEC 801-4
Safety EN 600947-1 Related to safety requirements.
Designed and assembled to conform with UL508C
