Solcon RVS-DX Series User Manual

6 • Te chnical Da ta
________________________________________________________________________________________
3.3.2 Mains Voltage (line to line)
Four Main Voltage levels are available: 400V, 480V, 600V and 690V (690V only available for RVS-DX
390A and up).
Note:
400V applies for 230 to 400V.
3.3.3 Control Voltage
The Control Voltage (terminals A1(~) – A2 (N) operates the electronic circuitry and the bypass.
Two voltage levels are available, selectable by internal jumper:
230VAC + 10%-15%, 50/60 Hz (standard)
115VAC+ 10%-15%, 50/60 Hz
Refer to section
8.1 on page 49 for instructions on setting control voltages on site.
3.3.4 Other Options
More options are available for the RVS-DX. (Refer to section
3.3.6 on page 7.):
Communication, Analog card, harsh environment treatment, , Remote panel,UL & cUL approval .
3.3.5 Starter selection tables for various voltage ratings.
1
The starter selection table below concern standard, 1500r.p.m. 50Hz,
three-phase motors.
2
These values are given for guidance and may vary according to motor
manufacturer and depending on the number of poles.
3
It is the user’s responsibility to make sure that motor’s FLA will never
exceed Starter’s FLC.
3.3.5.1 Starter selection for 230V, 400V, 480V, 600V
Note:
C – Consult factory
Starter type
Starter
FLC
[A]
Motor
kW
@230V,
starter
“In-Line”
[kW]
Motor
kW
@230V,
starter
“Inside
Delta”
[kW]
Motor
kW
@400V,
starter
“In-Line”
[kW]
Motor
kW
@400V,
starter
“Inside
Delta”
[kW]
Motor
kW
@480V,
starter
“In-Line”
[kW]
Motor
kW
@480V,
starter
“Inside
Delta”
[kW]
Motor
kW
@600V,
starter
“In-Line”
[kW]
Motor
kW
@600V,
starter
“Inside
Delta”
[kW]
RVS-DX 8
8
1.5
3
3
6.5
4
8
5.5
9
RVS-DX 17
17
4
8
8
12.5
9
15
12.5
22
RVS-DX 31
31
8
15
15
25
18.5
30
25
40
RVS-DX 44
44
12.5
22
22
37
25
45
30
59
RVS-DX 58
58
15
30
25
51
37
59
45
80
RVS-DX 72
72
20
37
37
59
45
80
59
100
RVS-DX 85
85
25
40
45
80
55
90
59
110
RVS-DX 105
105
30
55
55
90
59
110
80
147
RVS-DX 145
145
40
75
75
132
90
160
110
200
RVS-DX 170
170
51
90
90
160
110
200
140
250
RVS-DX 210
210
59
110
110
184
140
220
160
295
RVS-DX 310
310
90
160
160
257
200
355
257
450
RVS-DX 390
390
110
200
200
355
257
475
315
560
RVS-DX 460
460
140
220
250
400
295
560
400
670
RVS-DX 580
580
180
315
315
560
400
670
500
RVS-DX 650
650
c
c
c
c
c
c
c
c
RVS-DX 820
820
250
450
450
670
560
670
RVS-DX 950
950
295
500
500
670
-
RVS-DX 1100
1100
355
560
600
-
