7 • Te chnical Da ta
___________________________________________________________________________________________
3.3.6 Ordering Information
8, 17, 31, 44, 58, 72, 85, 105, 145, 170, 210, 310, 390, 460, 580, 650, 820, 950, 1100
230-400VAC + 10%-15%, 50/60 Hz
480VAC + 10%-15%, 50/60 Hz
600VAC + 10%-15%, 50/60 Hz
690VAC + 10%-15%, 50/60 Hz (690V only available for RVS-DX 390A and up)
115VAC + 10%-15%, 50/60 Hz
230VAC + 10%-15%, 50/60 Hz
• Control voltage can be changed on site for RVS-DX up to 310A.
• For RVS-DX 390A and up control voltage must be ordered from factory.
Communication RS-485 (MODBUS)
(1)
Communication Profibus PCB (RVS-DX210-1100A)
(2)
Communication RS-485 (MODBUS) and external DevieNet to Modbus Gateway
(1) (4)
Analog card – Thermistor in and Analog out
(1)
(2)
Harsh environment treatment
Remote panel mounting replacing the original panel.( supplied with 1.5 m cable)
(3)
UL & cUL approval (RVS-DX8-170A mains voltage up to 600V)
• For more than one option indicate, for example: 8+5 (Harsh environment and
analog out)
• Options must be factory installed.
•
(1)
From RVSDX-8A and up to RVS-DX44A - One option can be installed -
either Modbus communication (3M) or analog (5).
From RVS-DX58A and up - both options 3M & 5 can be installed. Both
options must be ordered as one package.
•
(2)
From RVS-DX210A and up - both options 3P & 5 can be installed. Both
options must be ordered as one package.
•
(3)
Remote keypad option available for RVS-DX 58A and up.
• Mains voltage of 690V only available for RVS-DX 390A and up.
•
(4)
External DeviceNet to Modbus Gateway is supplied when DeviceNet
communication link is ordered.
Example:
RVS-DX rated 820A, mains voltage- 230V, control voltage- 115V, Modbus communication card, Analog
card, Harsh environment treatment and standard front panel:
RVS-DX 820 - 400 - 115 - 3M+5+8 – S
