Solcon RVS-DX Series User Manual

27 • Control Keypad
___________________________________________________________________________________________
7.6.3 Main Parameters – page 1
MAIN PARAMETERS
- **** -
Displays in MINIMIZED MODE and MAXIMIZED MODE
(Refer below for changing modes)
Display and default
values
Range
Description
Remarks
LANGUAGE:
ENGLISH
SPANISH
GERMAN
FRENCH
ENGLISH
TURKCE
RUSSIAN
(Optional)
Sets Starter’s
language
STARTER FLC
58 AMP.
8–1100A
Sets starter’s
FLC (Full load
current)
Starter’s FLC should be as shown on starter’s
Name plate. (Refer to section 6.1 on page 18)
MOTOR FLA
58 AMP.
50-100% of
STARTER
FLC
Sets motor’s
FLA (Full load
Ampere)
Should be programmed as shown on motor’s
name plate.
Note:
When the RVS-DX is installed Inside Delta set
MOTOR FLA = <rated motor current>/1.73.
RATED POWER
30KW
1-3000KW
Sets motor’s
POWER
Rated motor power is used for analog output
reference. When analog card is installed, full
scale of the readings (20mA or 10V as per dip-
switches settings on the analog card) are related
to 200%FLA. (2x rated motor current) or 200% of
rated power or POWER FACTOR.
Refer to section
7.6.9 on page 42 for analog
output programming.
Note:
POWER FACTOR & POWER measurement only
available in RVS-DX58A and up.
CONNECTION TYPE
LINE
LINE,
INSIDE
DELTA
Sets Starter’s
connection
type.
Factory preset – features and functions when
“INSIDE DELTA” mode is configured:
No Pulse Start.
No Curve selection (CURVE 0!!).
No slow speed.
No phase sequence “off” mode.
Refer to section
4.3.9 on page 12 for further
information
RATED LINE VOLT.
400 VOLT
220-690V
Sets rated
LINE
VOLTAGE.
UNDERCURR. TRIP
0% OF FLA
0%=off;
20-90% of
FLA
Sets UNDER
CURRENT
TRIP
protection.
Trips the starter when motor current drops blow
set level for a time longer than UNDER
CURRENT DELAY
UNDERCURR. DELAY
10 SEC.
1-40sec.
Sets the time
delay for the
