Solcon RVS-DX Series User Manual

21 • Control Keypad
___________________________________________________________________________________________
7.3 Status LEDs.
Green
On
Lights when Control Supply voltage is connected to the RVS-DX.
Yellow
Ramp
Lights during soft start and soft stop process, indicating that motor supply voltage is
ramping up or down.
Green
Run
Lights after completion of starting process, indicating that motor is receiving full
voltage.
Red
Fault
Lights upon operation of any of the built-in protection.
7.4 Reviewing and Modifying Parameters
Press the Mode key several times until you reach the required mode page.
Press the Select key to review parameters for this mode.
Once you reach the required parameter, use the ▼ or ▲ keys to modify its value.
To store the new parameters, press the Select key until the STORE ENABLE message displays and then
press the Store key. The DATA SAVED OK message will display for 2 seconds.
7.5 Special Actions Performed in TEST/MAINTENANCE Mode
7.5.1 Run Self Test
Press the Mode and ▼ keys simultaneously.
The LCD will display:
TEST/MAINTENANCE
***OPTIONS***
Press the Select key.
The LCD will display:
RUN SELF TEST?
PUSH UP ARROW
Press the ▲ key.
The LCD will display:
SELF TEST PASSED
And after a few seconds the LCD will display:
% OF MOTOR FLA
I<0.1 FLC
7.5.2 View Software Version
Press the Mode and ▼ keys simultaneously.
The LCD will display:
TEST/MAINTENANCE
***OPTIONS***
Press the Select key twice.
The LCD will display:
BTL-R-17/05/2009
STRT.DX-310111
Press the Mode and ▼ keys simultaneously to exit the TEST/MAINTENANCE mode.
The LCD will display:
% OF MOTOR FLA
I<0.1 FLC
