Solcon RVS-DX Series User Manual

25 • Control Keypad
___________________________________________________________________________________________
Appears only in
MAXIMIZED MODE
(1)
Appears only in
MAXIMIZED MODE
(1)
Appears only in
MAXIMIZED MODE
(1)
Appears only in
MAXIMIZED MODE
(1)
SPECIAL FEATURES
PARAMETERS
FAULT PARAMETERS
I/O PROGRAMMING
PARAMETERS
COMM. PARAMETERS
STATISTICAL DATA
Refer page 38
Refer page 40
Refer page 42
Refer page 44
Refer page 46
SLOW SPEED TORQ.
8
PHASE LOSS Y/N
YES
PROG. INPUT C1
REMOTE RESET
COMM. PROTOCOL
MODBUS
TOTAL ENERGY
(3)
0 KWH
MAX SLOW SP TIME
30 SEC.
PHASE SEQ. Y/N
NO
FAULT RELAY TYPE
FAULT
BAUD RATE
9600 (MODBUS)
LAST STRT PERIOD
NO DATA
WIDER SETTINGS
DISABLE
INSULATION ALARM
OFF
PROG. AUX. RELAY
IMMEDIATE
PARITY CHECK
EVEN
LAST START MAX I
NO DATA
STORE ENABLE
SPECIAL FEATURES
INSULATION TRIP
OFF
RELAY ON DELAY
0 SEC.
SERIAL LINK NO.
OFF
TOTAL RUN TIME
0 HOURS
AUTO RESET
NO
RELAY OFF DELAY
0 SEC.
S. LINK PAR. SAVE
DISABLE
TOTAL # OF START
0
THERMISTOR TYPE
PTC
AN. OUT. PARAMETER
I, 0...200% OF FLA
SER. LINK CONTROL
DISABLE
LAST TRIP
NO DATA
THERMISTOR TRIP
OFF
STORE ENABLE
I/O PROG. PARAM.
MODBUS TIMEOUT
OFF
TRIP CURRENT
0 % OF FLA
UNDER CUR. RESET
OFF
FRONT COM ADDRES
OFF
TOTAL # OF TRIPS
0
STORE ENABLE
FAULT PARAMETERS
STORE ENABLE
COMM. PARAMETERS
PREVIOUS TRIP -2
NO DATA
Applicable when
Optional Modbus
or DeviceNet
is ordered.
.
.
.
Applicable when
Optional Profibus
Is ordered.
COMM. PROTOCOL
PROFIBUS
PREVIOUS TRIP -9
NO DATA
BAUD RATE
AUTO (PROFIBUS)
Appears when in
TEST/MAINTENANCE
(2)
PARITY CHECK
AUTO (PROFIBUS)
TEST/MAINTENANCE
***OPTIONS***
Display and default
values
PROFI.NETWORK ID
OFF
RUN SELF TEST?
PUSH UP ARROW
S. LINK PAR. SAVE
DISABLE
BTL-R-29/05/2008
STRT.DX-250608
SER. LINK CONTROL
DISABLE
STORE ENABLE
DEFAULT PARAMETERS
MODBUS TIMEOUT
OFF
RESET STATISTICS
FRONT COM ADDRES
OFF
VOLTAGE ADJUST
X VOLT
STORE ENABLE
COMM. PARAMETERS
CURRENT ADJUST
5% OF FLC
POWER FACTOR
(3)
0.71
(1)
- Refer to section 7.6.3 on page 27 for information on changing from “MINIMIZED MODE” (Factory default)
to “MAXIMIZED MODE”.
(2)
- Refer to section 7.5 on page 21 for entering TEST/MAINTENANCE mode.
(3)
– TOTAL ENERGY and POWER FACTOR readings available in RVS-DX 58A and up.
