DAW Control GuidE
5-10
AWS 900+ Owner’s Manual
Setting Sends Pre/Post Fader
When working with sends it is useful to be able to flip a send between pre and post fader.
If necessary select the PRE/POST button on the Master Control Panel.
Pushing a channel D-Pot will now switch the selected send on that channel between pre and post.
The green LED below the D-pot lights to show PRE is selected.
To change mode on all channels press and hold the OPT button then press any channel D-Pot. All channels will
switch to Pre or Post.
Muting a Send Output
To mute a send output select the MUTE button on the Master Control Panel and push the channel D-Pot. The
green LED below the channel D-Pot will light to show the channel is muted.
To mute or un-mute all channels press and hold the OPT button then press any
channel D-Pot. All channels will mute or un-mute.
Flipping Send Levels to the Faders
To flip Send levels from the D-Pots to the channel faders, press the Master Send
D-Pot marked ‘Push to Flip’).
The channel faders now control the send levels and the fader CUT button will
mute the send.
The channel D-Pot controls panning on stereo sends.
In this mode PRE/POST mode is automatically selected for the D-Pot switches, so
pushing a D-Pot will toggle the Send pre/post selection on that channel. The green
LED below the D-Pot lights to show PRE is selected.
The fader SOLO button will solo the channel, not the send.
