MCU Control Guide
AWS 900+ Owner’s Manual
5a-11
The Sonar Template
The AWS emulates a Mackie Control (MCU) plus two Logic XT fader expanders. The Control Surface set up menu
is located in the Sonar Options Menu.
To set up the correct mapping of AWS faders to DAW channels, select Mackie Control from the Tools menu to
access the Properties page and the Configure Layout option. Full on-line operational documentation for the Mackie
Control and Expander (XT) functions can be accessed via the PC keyboard F1 key when the Control Surface
Properties dialogue is open.
AWS Sonar Control Key Layout
The majority of functions are controlled via dedicated keys with less reliance on the 8x8 key matrix located beneath
the screen than with the HUI version.
