S2/S2BW
Digital Color Doppler Ultrasound System
Chapter 12
Miscellaneous Functions
12.1 Annotation
The annotation function allows the user to add textual comments or arrows on the ultrasound image using the
keyboard.
12.1.1 Textual Annotation
Annotation is used for doctor to mark on the ultrasound image. The functions consist of: Comment, Edit,
Modify, Move, Insert, Arrow, Delete and Clear.
When multiple comments are on screen, different colors are used to differentiate the comments. Multiple
languages for comments are supported and can be configured in system setting.
During a ultrasound scan, press key to enter annotation state. The cursor is changed to |, and the user
can enter texts directly using the keyboard or select an annotation string from the annotation library.
P/N: 4710.00149A01
12-1
