1-7. Switch Settings on Boards
1-7-1. BRC-300/300P
n
Never change the settings of the factory use switches.
SW-1204 Board
Ref. No. Name Description Factory setting
S2201 IR SELECT Selects a camera number when one remote commander 1
is used for multiple cameras.
S2202 75 Z termination switch 75 Z termination ON/OFF switch for the EXT SYNC IN ON
connector
S2201S2202
SW-1204 BOARD (SIDE A)
