1-9. Connectors and Cables
When connecting an external cable to the connector of each unit, use the following connector (or cable),
or equivalent.
Model Panel indication Matching connector/cable Sony part No.
BRC-300 VIDEO OUT BNC 75 Z coaxial cable —
BRC-300P EXT SYNC IN or,
BNC 75 Z, MALE 1-569-370-12
S VIDEO OUT S video cable —
DC IN 12 V ADAPTOR, AC (supplied accessory) ! 1-468-626-52
VISCA RS-232C IN VISCA RS-232C cable (cross type) 1-590-879-31
VISCA RS-232C OUT
VISCA RS-422 Connector plug 9P (supplied accessory) 1-818-103-11
and wire AWG No. 28 to 18
(cable length: max. about 1.2 km)
BRU-300 VIDEO OUT BNC 75 Z coaxial cable —
BRU-300P EXT SYNC IN or,
EXT SYNC OUT BNC 75 Z, MALE 1-569-370-12
S VIDEO OUT S video cable —
CAMERA Optical fiber cable CCFC-M100 —
VISCA RS-232C IN VISCA RS-232C cable (cross type) 1-590-879-31
VISCA RS-232C OUT
VISCA RS-422 Connector plug 9P (supplied accessory) 1-818-103-11
and wire AWG No. 28 to 18
(cable length: max. about 1.2 km)
RM-BR300 DC IN 12 V ADAPTOR, AC (supplied accessory) ! 1-468-626-52
VISCA RS-232C OUT VISCA RS-232C cable (supplied accessory) 1-590-879-31
VISCA RS-422 Connector plug 9P (supplied accessory) 1-818-103-11
TALLY/CONTACT and wire AWG No. 28 to 18
(cable length: max. about 1.2 km)
BRBK-301 RGB/SYNC OUT Connecting cable CCXC-9DD/9DB —
or,
D-SUB 9P, MALE 1-560-651-00
BRBK-302 SDI OUT BNC 75 Z coaxial cable —
or,
BNC 75 Z, MALE 1-569-370-12
BRBK-303 OPTICAL Optical fiber cable CCFC-M100 —
BRBK-304 DV OUT i.LINK cable VMC-IL6615B/CCF-3L —
