3-1
BRC-300/300P
BRU-300/300P
Fixtures
. Pattern box
PTB-700: J-6431-850-A
PTB-500: J-6029-140-B
. Clear chart: J-6080-621-A
. Color-bar chart
For PTB-700: J-6027-100-A
For PTB-500: J-6020-250-A
. Siemens star: J-6080-875-A
. Lens filter
ND filter 0.4: J-6080-806-A
ND filter 0.1: J-6080-807-A
ND filter 1.0: J-6080-808-A
Color temperature correction filter C14: J-6080-058-A
. Control software
FCB-A control soft: J-6432-770-B
. FCB interface tool board: J-6432-430-A
. Extension harness 10P-10P: J-6432-180-A
. Extension harness 9P-9P: J-6432-190-A
. Camera adjustment commander: J-6082-053-B
. Relay tool for Adjustment commander: J-6431-930-A
. Extension board EX-947: J-6433-230-A
3-1-2. Menu
This section partially uses the ANALOG OUT menu of the
BRC-300/300P for adjustments.
Perform the following procedure to set the ANALOG OUT
menu.
n
To display the ADJUST menu, press the DATA SCREEN
button of the SIRCS remote commander while S002 on the
EX-947 board is set to ADJ or S1003-3 on the SY-314
board is set to ON.
1. Turn on the power of the BRC-300/300P.
2. Press the DATA SCREEN button of the SIRCS remote
commander to display the main menu.
3. Press the
/ button of the SIRCS remote commander
to move the cursor to “ANALOG OUT”.
4. Press the HOME button of the SIRCS remote com-
mander to display the ANALOG OUT menu.
5. Press the
/ button of the SIRCS remote commander
to change the setting.
6. Press the DATA SCREEN button of the SIRCS remote
commander twice to exit the menu.
Section 3
Electrical Alignment
3-1. Overview
3-1-1. Tools/Equipment
The following are the tools/equipment required for electri-
cal alignment of all the models.
Refer to the corresponding section for tools/equipment
required for each model.
Measuring Tools/Equipment
. Oscilloscope
. SC detection tool
n
Use the test signal generator TG-7 (SHIBASOKU) or
equivalent.
. Frequency counter
. SDI waveform monitor
. Waveform monitor
. Vectorscope
. Color monitor (for SDI input)
. 75 Z terminator
. PC (personal computer)
OS: Windows NT3.5/4.0 or Windows 95/98/2000/XP
. 3CCD color video camera BRC-300/300P
. SIRCS remote commander (Supplied with the BRC-300/
300P)
. Optical multiplex unit BRU-300/300P
. Optical fiber cable CCFC-M100
. VTR with the DV input (i.LINK) connector
. IEEE1394 cable
