Sony BRC-300 - Connection for Adjustment

3-5
BRC-300/300P
BRU-300/300P
Pattern box
(PTB-700/PTB-500)
CAMERA block
Waveform monitor
Vectorscope
Color monitor
Adjustment
commander
(J-6082-053-B)
Relay tool
(J-6431-930-A)
75 Ω termination
DC
VIDEO
RS232C
+
Power supply
DC 9 V
Interface board
(J-6432-430-A)
Personal computer
System
Signal generator
3.0 ±0.1 V Duty : 50 %
NTSC : 60 Hz / PAL : 50 Hz
IF-110
DD-208
CN402 (10P)
_
10P
CN151 (9P)
9P
CN403 (LANC)
3-2-2. Connection for Adjustment
3-2. BRC-300/300P Camera Block Electrical Alignment
