3-4
BRC-300/300P
BRU-300/300P
Vectorscope scale
Copy on a transparent sheet according to the screen size of the vectorscope to be used.
<For NTSC model>
<For PAL model>
B-Y
R-Y
Mg
R
YL
G
B
Cy
Burst positon
B-Y
R-Y
Burst positon
YL
R
G
B
Cy
Mg
3-2. BRC-300/300P Camera Block Electrical Alignment
