1-20
BRC-300/300P
BRU-300/300P
SW-1207 Board
Ref. No. Bit Name Description Factory setting
S4901 1 RS-232C/RS-422 Selects RS-232C or RS-422. OFF (RS-232C)
ON: RS-422
OFF: RS-232C
2 9600bps/38400bps Sets communication baud rate. OFF (9600 bps)
ON: 38400 bps
OFF: 9600 bps
3 Camera address setting switch Sets a camera address.
*
0 (All OFF)
4
5
6 — Factory use OFF
*: Camera address setting
Camera addresses
01234567
S4901-3 OFF ON OFF ON OFF ON OFF ON
S4901-4 OFF OFF ON ON OFF OFF ON ON
S4901-5 OFF OFF OFF OFF ON ON ON ON
S4901
SW-1207 BOARD (SIDE A)
