Sony BRC-300 - Page 84

3-18
BRC-300/300P
BRU-300/300P
Page: E
0x 1x 2x 3x 4x 5x 6x 7x 8x 9x Ax Bx Cx Dx Ex Fx
x0 00 00 00 A5 3C B3 78 10 F0 67 70 38 6C 46 1C 9F
x1 00 04 04 53 06 80 CD 0F 8C A0 77 48 60 AA A6 90
x2 00 04 0C 69 06 4F DD 1E 35 C0 7C 30 27 32 00 A0
x3 00 09 F8 47 62 DC CD 00 5A 44 AB 3F 18 88 F0 0F
x4 30 0E 00 30 4A 0F DD 44 6C 10 68 00 00 30 00 00
x5 30 00 00 4D 36 C5 A8 A0 57 27 87 00 00 60 C0 0F
x6 62 81 00 0A 9E A4 23 3D 8B 27 75 00 00 01 76 00
x7 0A 07 23 08 2D 60 7C 58 00 62 B0 00 00 E5 89 A7
x8 00 10 63 40 20 78 20 00 00 62 86 00 20 5C 11 00
x9 00 FC 10 DC 10 00 70 24 48 73 AA 00 20 A4 77 00
xA 00 02 7A 24 22 03 4D 14 90 CA 83 06 14 5A 8C 98
xB 00 FF 08 C0 32 00 3A 33 00 FF A3 05 FC B3 9E 65
xC 00 00 F8 3C BA 9C 5C 54 44 87 38 23 20 22 05 53
xD 00 04 08 DC 00 F0 5C 36 10 5F 69 40 40 33 00 0A
xE 00 18 08 24 00 54 5C 42 33 83 E8 6C 88 30 00 A2
xF 00 EC 3E C0 84 C8 39 46 2A AB 90 60 63 00 3D E1
Page: F
0x 1x 2x 3x 4x 5x 6x 7x 8x 9x Ax Bx Cx Dx Ex Fx
x0 FF 40 80 00 0A F0 11 00 00 00 00 62 D5 5B 40 1F
x1 FF 80 80 23 19 FF EB 80 00 00 00 24 70 2F 50 1F
x2 FF 4F 80 2C 07 00 53 80 00 00 00 30 50 08 00 50
x3 FF 80 80 C2 DD 00 0A 80 00 00 00 21 77 00 06 10
x4 FF 90 FF 26 04 00 1E 80 80 00 00 1C 00 00 00 30
x5 FF 18 20 68 EB 00 AC 40 80 00 00 90 7F 02 03 00
x6 FF 75 00 2D D5 00 00 C0 50 00 00 76 80 A8 8F AB
x7 FF 4A 08 64 40 FF 00 40 50 00 00 7A 64 CC 00 C0
x8 FF 89 00 01 40 00 00 C0 00 00 00 CB 1F 00 00 40
x9 FF 80 20 E8 04 FF 00 40 00 00 00 88 C3 00 00 00
xA FF 80 14 1B 00 FF 86 C0 01 00 00 54 5B 00 06 10
xB FF 7A 17 24 00 0F 19 40 E0 00 00 38 1F 5D 00 00
xC FF 80 04 2C 00 FF 19 C0 80 00 00 61 00 13 10 40
xD FF 80 79 F4 7F FF 38 20 80 00 00 2B 87 77 40 40
xE FF 80 00 59 FF FF 00 00 80 00 00 13 04 00 00 FF
xF FF 80 00 B0 00 0F 00 00 20 00 00 89 32 00 00 0F
3-2. BRC-300/300P Camera Block Electrical Alignment
