Sony DNW-A100 - Connector Panel

Chapter 2 Location and Function of Parts
2-22 Chapter 2 Location and Function of Parts
2-2 Connector Panel
75Ω
ON
OFF
75Ω
ON
OFF
DIGITAL INPUT
SDDI
(OPTION)
SDI SDDI SDI
DIGITAL OUTPUT
1
2
1
2
AUDIO INPUT
AUDIO OUTPUT
TIME CODE
MONITOR OUTPUT
VIDEO INPUT VIDEO OUTPUT
REF.VIDEO COMPOSITE COMPONENT
(OPTION) (OPTION)
Y
R-Y
B-Y
COMPONENT
(OPTION)
Y
R-Y
B-Y
1
2
3
COMPOSITE
(SUPER)
ALTERNATIVE
SCSI REMOTE(9P) RS-232C VIDEO CONTROL
600Ω
AC IN
BREAKER
LOW HIGH
OFF ON
CH1
LEVEL
600Ω
LOW HIGH
OFF ON
CH4
LEVEL
600Ω
LOW HIGH
OFF ON
CH3
LEVEL
600Ω
LOW HIGH
OFF ON
CH2
LEVEL
IN OUT
CH1 CH2 CH3
CH4 R L
2-2 Connector Panel
Cooling fan
Cooling fan
2 Analog video input/output section (See page
2-23.)
1 Analog (digital: option) audio input/output section (See page
2-23.)
3 Digital input/output section (See
page 2-24.)
4 Time code input/output section and audio monitor signal
output section (See page 2-24.)
5 External device connectors (See page 2-25.)
6 Power supply section (See page 2-25.)
