Chapter 2 Location and Function of Parts
Chapter 2 Location and Function of Parts 2-1
2-1 Control Panels
Chapter 2 Location and Function of Parts
There are three front control panels, as follows:
Upper control panel
Subsidiary control panel
Lower control panel
Lower control panel
(See page 2-8.)
Subsidiary control panel
(See page 2-19.)
Upper control panel
(See page 2-2.)
To reveal the subsidiary control panel, pull the lower control panel forward.
