1-2 Example System Configurations
The following conceptual diagrams show examples of
use in an outside broadcast van or local station and
within a broadcasting station.
•Operation in an outside broadcast van or local station
•Operation in a broadcasting station
Betacam SX camcorder
Betacam SP camcorder
Analog cassette
Digital cassette
Microphone
Portable editor
Digital (SDDI/SDI)
Analog
composite
Analog audio
Video monitor
Audio monitor
SNG
a)
system
Digital modulator
Digital
demodulator
a) SNG: Satellite News Gathering
Digital/analog cassette
BVE-series editor
a)
Tape control
Analog composite
Audio monitor
Microphone
On-line editor (for cut editing)
Digital cassette
Analog composite/component
Analog
composite
DNW-A100/A100P
DNW-A100/A100P
Video monitor
Additional
hard disks
VTR with SDI connectors
or analog VTR
Audio/video
server
system
a) You cannot control this unit as a recorder using a BVE-series editor.
SDDI
SDI
SCSI
SDIAnalog audio
