Sony DSR-2000A - Reel Shift Motor Assembly Replacement

7-51
DSR-2000A/2000AP
7-18. Reel Shift Motor Assembly Replacement
Outline
Replacement
Removing the pinch limiter assembly
Removing the pinch solenoid assembly
Replacing the reel shift motor assembly
Reattaching the pinch solenoid assembly
Reattaching the pinch limiter assembly
Note
Prepare a new stop washer when replacing the reel shift motor assembly.
Stop washer (1.5) : 3-669-465-01 x 1 (for mounting the pinch limiter assembly)
Preparation
1. Set the unit to the unthreading end status.
2. Power off the unit.
3. Remove the top panel. (Refer to Section 3-3)
4. Remove the cassette compartment. (Refer to Section 3-4)
Tools
. Torque screwdriver’s bit (for M1.4) : J-6325-110-A
. Torque screwdriver (for 3 kgf.cm) : J-6325-400-A
. Washer extracting fixture (A) : J-6082-234-A
. Washer mounting fixture Ø1.5 : J-6082-231-A
. Cleaning cloth : 3-184-527-01
. Cleaning fluid : 9-919-573-01
. Tweezers
