Sony DSR-2000A - Audio Adjustment; Audio OUTPUT Level Adjustment; Audio EE Level Adjustment

10-4
DSR-2000A/2000AP
Specification
AUDIO OUTPUT 1/3 & 2/4 (600 Z loaded)
Spec. +4.0 ±0.1 dBm
Specification
AUDIO OUTPUT 1/3 & 2/4 (600 Z loaded)
Spec. +4.0 ±0.3 dBm
Conditions for adjustment
. MENU
ENHANCED
↓
AU REF LEVEL ; _20 dB (for NTSC)
_18 dB (for PAL)
OUTPUT LEVEL ; +4 dB
VIDEO INPUT SELECT ; SG
AUDIO INPUT SELECT ; SG
. AUDIO REC & PB AUDIO VR/
Control panel ; PRESET
. PB mode
1 kHz Ref. level (32 kHz ; 4CH)/SG (1 kHz)
10-2. Audio Adjustment
10-2-1. Audio OUTPUT Level Adjustment
10-2-2. Audio EE Level Adjustment
Adjustment
CH-1 ;
1RV201/APR-45 (L-1)
CH-2 ;
1RV202/APR-45 (L-1)
CH-3 ;
1RV203/APR-45 (L-1)
CH-4 ;
1RV204/APR-45 (M-1)
Conditions for adjustment
. MENU
ENHANCED
↓
AU REF LEVEL ; _20 dB (for NTSC)
_18 dB (for PAL)
OUTPUT LEVEL ; +4 dB
VIDEO INPUT SELECT ; SG
AUDIO INPUT SELECT ; ANALOG
. AUDIO REC & PB AUDIO VR/
Control panel ; PRESET
. AUDIO INPUT CH-1/CH-2/CH-3/CH-4 ;
1 kHz, +4 dBu
. EE mode
Adjustment
CH-1 ;
1RV1/APR-45 (M-3)
CH-2 ;
1RV4/APR-45 (N-3)
CH-3 ;
1RV101/APR-45 (P-3)
CH-4 ;
1RV104/APR-45 (P-3)
