Sony DSR-2000A - Sdi;Sdti; Free Run Adjustment

10-18
DSR-2000A/2000AP
Adjustment
1RV751/APR-45 (A-1)
1RV1501/APR-45 (A-1)
1RV1551/APR-45 (F-1)
1RV701/APR-45 (A-2)
1RV801/APR-45 (C-2)
Conditions for adjustment
Step 1
. E-E mode
. Connect jumper wire between TP1501/
APR-45 (C-2) and E704/APR-45 (A-1).
. After adjustment, remove jumper wire.
Step 2
. E-E mode
. Connect jumper wire between TP1551/
APR-45 (E-2) and E1501/APR-45 (E-1).
. After adjustment, remove jumper wire.
. E-E mode
. Connect jumper wire between TP801/
APR-45 (B-1) and E704/APR-45 (A-1).
. Select SDTI with INPUT SELECT.
. After adjustment, remove jumper wire.
10-4. SDI/SDTI
10-4-1. Free Run Adjustment
(Connection)
Specification
TP751/APR-45 (A-1)
TP1502/APR-45 (E-1)
Spec. 27.0 ±0.1 MHz
TP1552/APR-45 (E-1)
Spec. 27.0 ±0.1 MHz
Step 1
TP701/APR-45 (A-2)
Spec. 27.0 ±0.1 MHz
Step 2
TP802/APR-45 (B-4)
Spec. 27.0 ±0.1 MHz
DSR-2000A/2000AP
APR-45 (TP)
Oscilloscope Frequency counter
