Sony DSR-2000A - On-Board Switch Setting

2-12
DSR-2000A/2000AP
2-9-3. On-board Switch Setting
SV-212 board
n
Do not change the setting of switches when the “factory use” is shown in the description.
Ref No. Description Factory Setting
S101-1 HOURS METER can enter reset mode. OFF
S101-2 factory use OFF
S101-3 Use this switch when operating the machine with cassette compartment removed. OFF
S101-4 This defeats an error detection of mechanism and setvo system alignment. OFF
S101-5 factory use OFF
S101-6 factory use OFF
S101-7 factory use OFF
S101-8 factory use OFF
S101
A
B C
D
E F G H J K L
M
N
P
1
2
3
4
5
6
SV-212 BOARD (A SIDE)
