7-12
DSR-2000A/2000AP
7-4. Brake Solenoid Replacement
Outline
Replacement
Removing the MD cover
Disconnecting the connector
Removing the brake assembly
Replacing the brake solenoid
Reattaching the brake assembly
Reconnecting the connector
Reattaching the MD cover
Checking the performance
Note
Prepare a new stop washer when replacing the brake solenoid.
Stop washer (1.5) : 3-669-465-01 x 1
Preparation
1. Set the unit to the unthreading end status.
2. Power off the unit.
3. Remove the top panel. (Refer to Section 3-3.)
4. Remove the bottom panel. (Refer to Section 3-3.)
5. Remove the right side panel. (Refer to Section 3-3.)
6. Remove the cassette compartment. (Refer to Section 3-4.)
Tools
. Torque screwdriver’s bit (for M1.4) : J-6325-110-A
. Torque screwdriver’s bit (for M2) : J-6325-380-A
. Torque screwdriver (for 3 kgf.cm) : J-6325-400-A
. Washer extracting fixture (A) : J-6082-234-A
. Washer mounting fixture Ø1.5 : J-6082-231-A
. Tweezers
