Sony DSR-2000A - 5 Maintenance Menu; Menu Structure

5-1
DSR-2000A/2000AP
Section 5
Maintenance Menu
5-1. Menu Structure
This unit has a maintenance menu which is used for maintenance.
The maintenance menu has a layered structure through which you move to perform the various checks, settings and
adjustments using the specified menu items. Contents of the maintenance menu are displayed on the video monitor
connected to the VIDEO OUT 3 (SUPER) connector or the SDI OUTPUT 3 (SUPER) connector and the time counter of
DSR-2000A/2000AP.
Values in parenthesis ( ) are time counter display.
MENU, First layer MENU, Second layer MENU, Third layer
MENU DATA CONTROL MENU STATUS DISPLAY (>MENU STA)
(MENU CNT) SAVE MENU DATA (>Save MENU)
LOAD MENU DATA (>Load MENU)
SERVO CHECK (SV Check) SENSOR CHECK (>Sensor) CASS-COMPARTMENT (>>Cass-COM)
TAPE TOP/END (>>Top/End)
HUMID [MOISTURE] (>>HUMID)
REC INHIBIT (>>REC INHI.)
MOTOR CHECK (>Motor) S-REEL (>>S-Reel)
T-REEL (>>T-Reel)
THREADING (>>Threading)
CASS-COMPARTMENT (>>Cass-COM)
CAPSTAN (>> Capstan)
DRUM (>>Drum)
REEL POSITION (>>Reel POS.)
PLUNGER CHECK (>Plunger) PINCH (>>Pinch)
REEL BRAKE (>>R-Brake)
M PLUNGER (>>M Plunger)
HEAD CLEANER (>>H. Cleaner)
SERVO ADJUST (SV Adjust) S/T-REEL & CAPSTAN (>Reel & Cap.)
S-REEL ONLY (>S-Reel)
T-REEL ONLY (>T-Reel)
CAPSTAN ONLY (>Capstan)
TENSION (>Tension)
TAPE PATH ADJUST (TP Adjust) TRACKING ADJUST (>Tracking)
RF SWITCHING POSITION (>Switching)
