3-9
DSR-2000A/2000AP
Removal/Reattachment of the Top Panel
(1) Loose the three screws and remove the top panel in the
arrow direction.
n
The screws do not come off the top panel, because of a
stopper attached to the screw.
Do not forcibly remove the screws from the top panel.
(2) Insert the two claws of the top panel in the section A
shown in the figure, and tighten the three screws to
reattach the top panel.
Removal/Reattachment of the Bottom Panel
(1) Place the unit with the right side panel facing down.
(2) Remove the six screws and remove the bottom panel.
(3) With the claw of the bottom panel positioning as
shown in the figure, fit the four holes in the bottom
panel on the feet.
(4) Tighten the six screws to reattach the bottom panel.
Removal/Reattachment of the right and left side
panels
[Reference][Reference]
[Reference][Reference]
[Reference]
A same procedure is performed when removing/reattach-
ing the right and left side panels.
(1) Remove the four screws shown in the figure and
remove the side panel.
(2) Hook the side panel at the three claws in the chassis,
and while pulling the side panel in the arrow direction,
tighten the four screws (B4 x 6).
Removal/Reattachment of the front panel
(1) Remove the top panel.
(2) Remove the two screws securing the front panel.
(3) Insert hands in the space between the front panel and
the chassis and pick up the upper rim of the front
panel, and then release the four claws of the front
panel.
(4) Pull out the front panel to your side and detach it.
(5) While hooking the four claws of the front panel at the
three crooks of the chassis and the crook of the
cassette compartment holding assembly, insert the two
protrusions to the notch and hole of the chassis.
(6) While pressing the front panel against the unit, fix the
front panel with the two screws.
To Next Page
