3-36
DSR-2000A/2000AP
Message
VTR Status
Erasing flash memory.
Writing flash memory.
Completed download.
Unable to access to flash memory. Flash ROM device error, Writing error
Unable to erase of flash memory. Flash ROM erasure error
Verify Error occurs. Verify-error in writing into flash memory
Checksum error occurs. Checksum error in data received from a PC
Communication error occurs in Overrun, flaming, parity error
VTR and PC
PC Status
Trying communication with a PC. Starts at the pressing the Start button and ends until VTR
starts to erase flash memory.
Communication with a VTR is stopped. A user pressed Cancel button.
Message Box
No response from a VTR
Can’t set a VTR to remote mode.
Can’t set a VTR to adjustment mode.
Can’t set a VTR to download mode.
File not found. When Start button is pressed, if a file is not found.
Can’t open a port.
When Start button is pressed, RS-232C COM prot does not open.
A VTR interrupts communication. Before transfer finishes, a VTR finishes.
VFD Display
loading XX (XX : SY, SV, SP) Now loading
complete! Download is completed without fail.
incomplete! Download is abnormally terminated
Error91-130
SY flash ROM is abnormal. (Valid only in download mode.)
Error91-430
SV flash ROM is abnormal. (Valid only in download mode.)
Error91-730
SP flash ROM is abnormal. (Valid only in download mode.)
Error91-215 Waiting for data sent from a PC
(Communication error between SY and KY)
Power down a VTR once.
Monitor
ALARM
Now upgrading
After version upgrade
power down once.
After the version upgrade is completed, turn off and on the power of the VTR.
(In case of upgrading the same CPU or other CPU, it is not necessary to power down.)
If properly finished, confirm that CPU versions written in the MAINTENANCE MENU are correct.
