Sony HCD-DX50 - Panel Section Parts List

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
56
HCD-DX50/RG80
1-675-912-14 DRIVER BOARD
*************
< CAPACITOR >
C702 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
CN701 1-785-336-11 PIN, CONNECTOR(LIGHT ANGLE)10P
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
< DIODE >
D701 8-719-983-68 DIODE MTZJ-T-72-3.9A
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
************************************************************
1-676-220-11 HEAD (A) BOARD
**************
< CONNECTOR >
* CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
************************************************************
1-676-221-11 HEAD (B) BOARD
**************
CN2 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
************************************************************
A-2007-846-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20.00% 10V
< CONNECTOR >
CN1001 1-568-860-11 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
< IC >
IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-780-00 CARBON 7.5 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (A HALF)
S1005 1-771-205-11 SWITCH, LEAF (REC A)
S1006 1-771-333-11 SWITCH, LEAF (B HALF)
S1009 1-771-205-11 SWITCH, LEAF (REC B)
************************************************************
A-4475-789-A MAIN BOARD, COMPLETE (DX50: SP,AUS)
*********************************
A-4476-287-A MAIN BOARD, COMPLETE (DX50: E)
*****************************
A-4476-330-A MAIN BOARD, COMPLETE (DX50: MX,AR)
*********************************
A-4476-332-A MAIN BOARD, COMPLETE (DX50: KR)
******************************
A-4476-984-A MAIN BOARD, COMPLETE (RG80)
***************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C1 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C3 1-104-664-11 ELECT 47uF 20.00% 16V
C4 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C5 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C7 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C11 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C12 1-104-664-11 ELECT 47uF 20.00% 16V
C13 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C14 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C15 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C16 1-104-664-11 ELECT 47uF 20.00% 16V
C17 1-126-959-11 ELECT 0.47uF 20.00% 50V
C18 1-126-960-11 ELECT 1uF 20.00% 50V
C19 1-126-960-11 ELECT 1uF 20.00% 50V
C20 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
(DX50)
C20 1-164-245-11 CERAMIC CHIP 0.022uF 10.00% 25V
(RG80)
C21 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
(DX50)
C21 1-164-245-11 CERAMIC CHIP 0.022uF 10.00% 25V
(DX80)
C22 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C23 1-164-360-11 CERAMIC CHIP 0.1uF 16V
