Sony HCD-DX50 - Page 70

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
68
HCD-DX50/RG80
< SWITCH >
0 S901 1-786-055-11 SELECTOR, VOLTAGE (DX50: E,SP,AR)
< TRANSFORMER >
0 T972 1-435-867-11 POWER TRANSFORMER (DX50)
0 T972 1-435-864-11 POWER TRANSFORMER (RG80)
************************************************************
1-680-892-11 SWITCH BOARD
*************
< CONNECTOR >
CN607 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE)2P
< JACK >
J401 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< JUMPER RESISTOR >
JR781 1-216-864-11 SHORT 0
************************************************************
MISCELLANEOUS
**************
101 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
104 1-757-683-11 CABLE, FLAT (21 CORE)
0 108 1-696-847-11 CORD, POWER (DX50: AUS)
0 108 1-777-071-51 CORD, POWER (DX50: E51,SP)
0 108 1-783-941-12 CORD, POWER (DX50: AR)
0 108 1-791-901-11 CORD, POWER (DX50: E2,MX/RG80)
0 109 1-569-008-21 ADAPTOR, CONVERSION (DX50: E51,SP)
259 1-791-983-11 WIRE (FLAT TYPE) (8 CORE)
306 1-757-710-11 WIRE (FLAT TYPE) (16 CORE)
0 307 A-4735-188-A BU-30 (60) ASSY
HP901 A-2004-765-A BASE (A) ASSY, HEAD
HRPE901A-2004-766-A BASE (B) ASSY, HEAD
M721 A-4672-826-A MOTOR ASSY (TURN)
M901 X-3378-246-1 MOTOR ASSY (CAPSTAN)
M961 1-763-072-11 FAN, D.C.
PM901 1-454-887-11 PLUNGER
PM902 1-454-887-11 PLUNGER
0 T910 1-435-861-11 POWER TRANSFORMER (DX50)
0 T910 1-435-863-11 POWER TRANSFORMER (RG80)
************************************************************
**************
HARDWARE LIST
**************
#1 7-628-254-00 SCREW +PS 2.6X5
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-647-11 SCREW +BVTP 3X10
#4 7-685-648-11 SCREW +BVTP 3X12
#5 7-685-872-11 SCREW +BVTT 3X8
#6 7-685-881-11 SCREW +BVTT 4X8
SWITCH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
SUB TRANS
