Sony HCD-DX80 - Tape Mechanism Deck (TCM-230 AWR41); Back Panel Section

10
HCD-DX80
2-6. TAPE MECHANISM DECK (TCM-230AWR41)
2 Tape mechanism deck
(TCM-230AWR41)
1 five screws
(+BVTP 2.6
× 8
)
2-7. BACK PANEL SECTION
4 five screws
(+BVTP 3
× 10)
5 two screws
(+BVTP 3
× 10
)
1 connector (CN973)
2 connector (CN505)
6 back panel section
3 connector (CN891)
