Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
60
HCD-DX80
BD CD-SW
< IC >
IC101 8-752-402-31 IC CXD3017Q
IC102 8-759-827-41 IC BA5974FM-E2
IC103 8-752-089-74 IC CXA2581N-T4
< JUMPER RESISTOR >
JR101 1-216-295-11 SHORT 0
JR102 1-216-295-11 SHORT 0
JR103 1-216-295-11 SHORT 0
JR104 1-216-295-11 SHORT 0
JR105 1-216-295-11 SHORT 0
JR106 1-216-295-11 SHORT 0
JR122 1-216-296-11 SHORT 0
JR123 1-216-296-11 SHORT 0
JR124 1-216-296-11 SHORT 0
JR125 1-216-296-11 SHORT 0
< COIL >
L101 1-469-553-21 INDUCTOR 4.7uH
< TRANSISTOR >
Q101 8-729-010-08 TRANSISTOR MSB710-RT1
Q102 8-729-920-85 TRANSISTOR 2SD1664-T100-QR
< RESISTOR >
R101 1-216-049-11 RES-CHIP 1K 5% 1/10W
R102 1-216-097-11 RES-CHIP 100K 5% 1/10W
R103 1-216-077-00 RES-CHIP 15K 5% 1/10W
R104 1-216-085-00 METAL CHIP 33K 5% 1/10W
R105 1-216-049-11 RES-CHIP 1K 5% 1/10W
R106 1-216-049-11 RES-CHIP 1K 5% 1/10W
R107 1-216-073-00 METAL CHIP 10K 5% 1/10W
R108 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R109 1-216-121-11 RES-CHIP 1M 5% 1/10W
R111 1-216-099-00 METAL CHIP 120K 5% 1/10W
R114 1-218-745-11 RES-CHIP 160K 5% 1/16W
R116 1-216-001-00 METAL CHIP 10 5% 1/10W
R117 1-216-049-11 RES-CHIP 1K 5% 1/10W
R118 1-216-025-11 RES-CHIP 100 5% 1/10W
R119 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R120 1-216-077-00 RES-CHIP 15K 5% 1/10W
R122 1-216-097-11 RES-CHIP 100K 5% 1/10W
R123 1-216-073-00 METAL CHIP 10K 5% 1/10W
R124 1-216-097-11 RES-CHIP 100K 5% 1/10W
R131 1-216-033-00 METAL CHIP 220 5% 1/10W
R143 1-216-085-00 METAL CHIP 33K 5% 1/10W
R144 1-216-085-00 METAL CHIP 33K 5% 1/10W
R147 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-001-00 METAL CHIP 10 5% 1/10W
R158 1-216-083-00 METAL CHIP 27K 5% 1/10W
R159 1-216-083-00 METAL CHIP 27K 5% 1/10W
R162 1-216-097-11 RES-CHIP 100K 5% 1/10W
R171 1-216-081-00 METAL CHIP 22K 5% 1/10W
R172 1-216-081-00 METAL CHIP 22K 5% 1/10W
R173 1-216-081-00 METAL CHIP 22K 5% 1/10W
R181 1-216-081-00 METAL CHIP 22K 5% 1/10W
R182 1-216-081-00 METAL CHIP 22K 5% 1/10W
R183 1-216-081-00 METAL CHIP 22K 5% 1/10W
R190 1-216-033-00 METAL CHIP 220 5% 1/10W
R191 1-216-085-00 METAL CHIP 33K 5% 1/10W
R192 1-216-085-00 METAL CHIP 33K 5% 1/10W
R193 1-216-099-00 METAL CHIP 120K 5% 1/10W
R194 1-216-097-11 RES-CHIP 100K 5% 1/10W
R195 1-216-113-00 METAL CHIP 470K 5% 1/10W
R196 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R198 1-216-295-11 SHORT 0
< COMPOSITION CIRCUIT BLOCK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< VARIABLE RESISTOR >
RV101 1-238-602-11 RES, ADJ, CARBON 47K
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
1-680-263-11 CD-SW BOARD
************
< LED >
D791 8-719-057-97 LED SEL5923A-TP15 (DISC 1)
D792 8-719-057-97 LED SEL5923A-TP15 (DISC 2)
D793 8-719-057-97 LED SEL5923A-TP15 (DISC 3)
D794 8-719-071-44 LED SEL5223C-TP15 (I/1)
< TRANSISTOR >
Q791 8-729-900-80 TRANSISTOR BA1A4M-TP
Q792 8-729-900-80 TRANSISTOR BA1A4M-TP
Q793 8-729-900-80 TRANSISTOR BA1A4M-TP
Q794 8-729-900-80 TRANSISTOR BA1A4M-TP
< RESISTOR >
R791 1-249-419-11 CARBON 1.5K 5% 1/4W
R792 1-249-421-11 CARBON 2.2K 5% 1/4W
R793 1-249-422-11 CARBON 2.7K 5% 1/4W
R794 1-249-424-11 CARBON 3.9K 5% 1/4W
R795 1-249-426-11 CARBON 5.6K 5% 1/4W
R796 1-249-410-11 CARBON 270 5% 1/4W
R798 1-249-409-11 CARBON 220 5% 1/4W
R799 1-249-409-11 CARBON 220 5% 1/4W
R800 1-249-417-11 CARBON 1K 5% 1/4W
R801 1-249-409-11 CARBON 220 5% 1/4W
< SWITCH >
S791 1-771-410-21 SWITCH, TACTILE (Z OPEN/CLOSE)
S792 1-771-410-21 SWITCH, TACTILE (DISK SKIP/EX-CHANGE)
S793 1-771-410-21 SWITCH, TACTILE (DISC 3)
S794 1-771-410-21 SWITCH, TACTILE (DISC 2)
S795 1-771-410-21 SWITCH, TACTILE (DISC 1)
S796 1-771-410-21 SWITCH, TACTILE (I/1)
**************************************************************
