Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
68
HCD-DX80
R820 1-216-821-11 METAL CHIP 1K 5% 1/16W
R821 1-216-841-11 METAL CHIP 47K 5% 1/16W
R822 1-216-842-11 METAL CHIP 56K 5% 1/16W
R823 1-216-833-11 METAL CHIP 10K 5% 1/16W
R824 1-216-841-11 METAL CHIP 47K 5% 1/16W
R825 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R826 1-216-839-11 METAL CHIP 33K 5% 1/16W
R827 1-216-837-11 METAL CHIP 22K 5% 1/16W
R829 1-216-837-11 METAL CHIP 22K 5% 1/16W
R830 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R831 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R832 1-216-845-11 METAL CHIP 100K 5% 1/16W
R841 1-216-837-11 METAL CHIP 22K 5% 1/16W
R842 1-216-837-11 METAL CHIP 22K 5% 1/16W
R843 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R844 1-216-845-11 METAL CHIP 100K 5% 1/16W
R845 1-216-857-11 METAL CHIP 1M 5% 1/16W
R854 1-216-841-11 METAL CHIP 47K 5% 1/16W
R861 1-216-821-11 METAL CHIP 1K 5% 1/16W
R862 1-216-833-11 METAL CHIP 10K 5% 1/16W
R863 1-216-841-11 METAL CHIP 47K 5% 1/16W
R864 1-216-821-11 METAL CHIP 1K 5% 1/16W
R865 1-216-821-11 METAL CHIP 1K 5% 1/16W
R866 1-216-806-11 RES-CHIP 56 5% 1/16W
0 R868 1-215-891-11 METAL OXIDE 680 5% 2W F
0 R869 1-215-891-11 METAL OXIDE 680 5% 2W F
R891 1-216-833-11 METAL CHIP 10K 5% 1/16W
R892 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R893 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R895 1-216-864-11 SHORT 0
R901 1-249-405-11 CARBON 100 5% 1/4W
R911 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R912 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R914 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R966 1-216-806-11 RES-CHIP 56 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB41 1-234-575-11 ENCAPSULATED COMPONENT
(AM FRONT-END)
< VARIABLE RESISTOR >
RV11 1-241-765-11 RES, ADJ, CARBON 22K
RV301 1-241-764-11 RES, ADJ, CARBON 10K
RV302 1-241-762-11 RES, ADJ, CARBON 2.2K
RV303 1-241-762-11 RES, ADJ, CARBON 2.2K
RV304 1-241-768-11 RES, ADJ, CARBON 220K
RV351 1-241-764-11 RES, ADJ, CARBON 10K
RV354 1-241-768-11 RES, ADJ, CARBON 220K
< RELAY >
RY801 1-755-372-11 RELAY
< TRANSFORMER >
T11 1-435-792-11 TRANSFORMER, DISCRIMINATOR
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM1 1-694-555-22 TERMINAL BOARD (4P) (ANTENNA)
TM801 1-694-635-12 TERMINAL BOARD (4P) (SPEAKER)
< VIBRATOR >
X51 1-760-549-31 VIBRATOR, CRYSTAL (4.5MHz)
X501 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X502 1-781-107-21 VIBRATOR, CERAMIC (16MHz)
**************************************************************
1-680-265-11 MAIN TRANS BOARD
*****************
1-533-233-11 HOLDER, FUSE
< CAPACITOR >
C941 1-128-553-11 ELECT 220uF 20% 63V
< CONNECTOR >
CN973 1-568-106-11 CONNECTOR 4P
CN977 1-564-528-11 PLUG, CONNECTOR 13P
< DIODE >
D977 8-719-024-99 DIODE 11ES2-NTA2B
< FUSE >
0 F971 1-532-506-31 FUSE, GLASS TUBE (T6.3AL/250V)
(EXCEPT MX)
0 F974 1-532-506-31 FUSE, GLASS TUBE (T6.3AL/250V)
0 F975 1-532-506-31 FUSE, GLASS TUBE (T6.3AL/250V)
0 F976 1-533-949-31 FUSE, GLASS TUBE (T8.0AL/250V)
0 F977 1-533-949-31 FUSE, GLASS TUBE (T8.0AL/250V)
< FUSIBLE >
0 R941 1-217-673-81 FUSIBLE 1 5% 1/4W F
0 R944 1-217-641-81 FUSIBLE 4.7 5% 1/4W F
0 R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
0 R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
0 R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
< TRANSFORMER >
0 T910 1-437-355-11 POWER TRANSFORMER (EXCEPT BR)
0 T910 1-437-284-11 POWER TRANSFORMER (BR)
**************************************************************
1-675-910-14 MOTOR BOARD
*************
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
CN722 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE) 4P
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE) (OPEN/CLOSE)
**************************************************************
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
MAIN MAIN TRANS MOTOR
To Next Page
